BIGTREETECH CEB V1.0 CANbus Expansion Board Perfect For 2020 Aluminum Profiles Support Klipper Ebb Sb2240 Sb2209 Ebb36 42 Can Octopus Pro H723 Manta M4p M5p M8p Control Board

Quick and Easy Installation BIGTREETECH CEB CANBUS breakout board frame is compatible with 2020 profiles and provides tool free installation printing. Directional Interfaces for Neat Wiring The board is designed in a way that ensures the wires exit in a uniform direction, promotes tidy wiring while improving the overall look. DIY-friendly BIGTREETECH CEB V1.0 breakout board reserve 120R terminal resistor selection jumper cap for customers to DIY use. Our open source housing is available for printing use, facilitating easier installation and protection of the CEB V1.0. Quick and Easy Installation: BIGTREETECH CEB V1.0 frame perfectly fits 2020 profiles and provides tool-free installation print files for easy installation in no time. Run Klipper Directional Interfaces for Neat Wiring: BIGTREETECH CEB V1.0 CANbus interface adapter board is designed in a way that ensures the wires exit in a uniform direction, promotes tidy wiring while improving the overall look. Comprehensive CAN Interface Support: Features a rich array of interfaces: Onboard 5Pcs XH2.54 2-pin ports+ screw terminal CAN bus interface, 1Pc XT30 connector, 1Pc RJ11 port, conveniently compatible with most CAN interfaces on the market. 6Pcs 120R terminal resistor selectable via jumper for DIY use. Widely Compatible: BTT CEB V1.0 Can Bus expansion board applicable to motherboards with CAN interface, such as Manta M8P/M5/M4P, Manta E3 EZ, Octopus Pro H723/Kraken/Octopus Max EZ/SKR 3/SKR 3 EZ board+EBB SB2209 CAN RP2040/EBB SB2240,EBB36/42 CAN Series. Attention: All wiring is performed without power; during installation, be sure to use a shell for protection and pay attention to the line sequence to prevent short circuits between the aluminum profile and the bottom pins of the board and communication errors.
